Stereo Zoom Microscope 7.5x – 50x Motic Microscopes SMZ 171 BLED TLED


Motic Microscopes SMZ 171 BLED Stereozoom Microscope (Binocular 7.5x – 50x)

Motic Microscopes SMZ 171 TLED Stereozoom Microscope (Trinocular 7.5x – 50x)


Motic Microscopes Dissection / Inspection Stereo Zoom SMZ 171 BLED TLED

SMZ 171 BLED is the binocular version of this popular quality stereo zoom microscope. TLED – Trinocular version for digital microscope camera adaption. The stand is fitted with energy efficient LED Incident and transmitted illumination. The base includes a tilting reflector and port for optional flexible light guide. A design feature to enable a higher intensity transmitted light source. Also useful for applications where colour temperature of a halogen light source is so important.

Motic Microscopes SMZ 171 BLED Stereo Zoom Microscope comprises:-

  • Greenough zoom optical system
  • Binocular head, 45° inclined, 360 rotating
  • Widefield eyepieces WF10X/23mm
  • 6.7:1 Zoom ratio, WD=110mm
  • Objective magnification range: 0.75x – 5x (Extendable)
  • SMZ-171 Pole type stand with large work area & head holder
  • Coarse focusing system with tension adjustment
  • 3W incident and transmitted LED illumination with intensity control Main supply 100V-240V (CE)
  • Transmitted light with tilting reflector (oblique illumination
  • Option to adapt flexible light guide
  • Main supply 100v – 240v (CE)
  • Black/White & Frosted glass stage plates & Dust cover
  • Contact MMS Microscopes for further information & quotation to meet your application needs here.

Additional information

Bino SMZ 171 BLED | Trino SMZ 171 TLED

Bino SMZ 171 BLED, Trino SMZ 171 TLED
